2PCS XL6009 DC-DC Boost Module Regulator Module Output Voltage Adjustable 0-4A Current
Description
- GLR6009SDC boost regulator module with voltage display function key to switch the input or output voltage measurement ; hasInput reverse polarity protection,output short circuit protection,over current protection measures overheating;All modules using high-quality components , materials stress , rational layout , attractive appearance, stable and reliable performance.
Module parameters:
- Module Properties:DC Boost RegulatorModules,XL6009;
- Input:Limits3.5V-32V,Recommended values5.0V-32V;
- Output voltage:Limits5.0V-38V; Output VoltageContinuously adjustable(Clockwise potentiometer voltage rises );
- LoseEnterCurrent:Limits0--4A,Recommended values0 - 3A;
- Conversion efficiency : Up95%;
- Switching frequency :150KHz,The second -generation switching power supply technology ;
- Working temperature:Limits :-30 To+70,Recommended values :-20 To+60,
- Full load temperature rise :Less than40 ;
- Output ripple : less than200mV;
- Short Circuit Protection : Output current limiting protection , automatic recovery;
- Reverse polarity protection : Input40VAnti- reverse protection;
Module interfaces:
- Wiring terminals connected via the input or output power , user-friendly
- IN +: Enter a positive level,
- IN-: Enter negative
- OUT + Positive output level,
- OUT- : Output negative
Module size :
- AppearanceSize :65*36* 15mm( Long*Wide*High )
- Fixed holes :3.0mm * 4A hole center distance plate edge3.5mm
- Please be assured that all modules purchased, the factory have been through a load test ! IfUserUnless otherwise specified , the module factoryThe output voltage isThe default is,Our last test at a load18VVoltage !
