35V 2000uf Electrolytic Capacitor 10-Pack
  • 35V 2000uf Electrolytic Capacitor 10-Pack

  • SKU:22420
    (0 reviews)   Write a review(Get Thanksbuyer Points!)
  • Availability: In Stock     Reward Points: 1
  • Price:$5.25
  • Price in reward points: 53
  • Buy more, save more
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $5.15 $5.04 $4.88 $4.67 Contact US

35V 2000uf Electrolytic Capacitor 10-Pack
Specfications:
- Load life:85 centigrade 2000hours
- High ripple capabality
- Capacitance range:2000uF
- RoHS Compliant

Specfications:



ITEM Performance Characteristics
Operating Temperature Range -40+85°C                            -25 +85°C
Rated Voltage Range 35V
Capacitance Range 3300-68000uF 220-22000uF
Capacitance Tolerrance ±20%(120HZ,+20°C)
LeakageCurrent(+20°C,max) I≤0.02C (uA)
After 5  minutes whichever is greater measured with rated working voltage applited
Dissipation Factor
tan ,at20°C,120HZ)
LESS THAN THE VALUE UNDER TABLE (%)
 wv       d 35 51 63.5 76
      16 0.6 0.7 0.8 1.2
      25 0.4 0.5 0.7 0.8
      35 0.3 0.5 0.6 0.7
      50 0.25 0.3 0.5 0.6
      63 0.2 0.25 0.3 0.4
      80 0.2 0.2 0.25 0.3
      100 0.15 0.2 0.25 0.3
      160-250 0.15 0.15 0.2 0.2
      350-450 0.2 0.2 0.25 0.3
Dissipation Factor
tan ,at20°C,120HZ)
Z-25°C/Z+20°C 3
Z-40°C/Z+20°C 12
Load life Test condition
Duration time 2000 hours
Ambient temperature 85°C
Applited voltage Rated DC working voltage
After test requeirement at +20°C
Capacitance change  ≤ ±15% of the initial  measured value
Dissipation factor  ≤ ±175% of the initial specified value
Leakage current  ≤ not more than  the initial specified value
Shelf Life Test condition
Duration time 1000Hrs
Ambient temperature +85°C
Applited voltage none
After test requeirement at +25°C
Capacitance change  ≤ ±15% of the initial  measured value
Dissipation factor  ≤ ±175% of the initial specified value
Leakage current  ≤ not more than  the initial specified value
