AD Module DA Module ADC0832 Digital Module Transfer Singlechip Board
Interface definition:
- Left interface:
VCC: positive power, connect to 5V
DIN: DA5615 data pins, connect to singlechip
DCK:DA5615 data pins, connect to singlechip
DCS:DA5615 data pins, connect to singlechip
ACK:ADC0832 data pins, connect to singlechip
ADO：ADC0832 data pins, connect to singlechip
ACS：ADC0832 data pins, connect to singlechip
GND: ground, 0V electric potential
- Right terminal pins definition:
DAO: DA converter output, this module can be easily connect to other controller
CH1: AD transfer second channel input, when green jumper cap is at OFF, AD signal can be external output, when it is at ON, then analog signal is input through 10K potentiometer
CH0: AD transfer first channel input, when green jumper cap is at OFF, AD signal can be external output, when it is at ON, then analog signal is input through 10K potentiometer
GND: reference O electric potential, ground
