ALIGN 250MX Brushless Motor(3600KV) RCM-BL250MX HML25M01
  • ALIGN 250MX Brushless Motor(3600KV) RCM-BL250MX HML25M01
  • ALIGN 250MX Brushless Motor(3600KV) RCM-BL250MX HML25M01
  • ALIGN 250MX Brushless Motor(3600KV) RCM-BL250MX HML25M01
  • ALIGN 250MX Brushless Motor(3600KV) RCM-BL250MX HML25M01
  • ALIGN 250MX Brushless Motor(3600KV) RCM-BL250MX HML25M01

  • SKU:24957
    (0 reviews)   Write a review(Get Thanksbuyer Points!)
  • Availability: In Stock     Reward Points: 4
  • Price:$35.90
  • Price in reward points: 359
  • Buy more, save more
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $35.18 $34.46 $33.39 $31.95 Contact US

ALIGN 250MX Brushless Motor(3600KV) RCM-BL250MX HML25M01

ALIGN 250MX Brushless Motor(3600KV) RCM-BL250MX HML25M01
ALIGN 250MX Brushless Motor(3600KV) RCM-BL250MX HML25M01
Specification Drawing:
ALIGN 250MX Brushless Motor(3600KV) RCM-BL250MX HML25M01
Wiring Schematic Drawing:
ALIGN 250MX Brushless Motor(3600KV) RCM-BL250MX HML25M01
ALIGN 250MX Brushless Motor(3600KV) RCM-BL250MX HML25M01

Features:

- The 250MX motor incorporates radial fan in its end bell, creating powerful airflow to dissipate heat. Tweaks to motor design and reduction in weight not only contributes to dramatic power increase, the high efficiency cooling system enables cooler operating temperature during and after flights when compared to motor of previous generation.
- The 250MX motor armature had a special balance adjust to improve the serious shaking problem that other tiny motors have.
- High torque, high efficiency, low temperature variant, stable and quiet.
- Japanese made high-speed ball bearings, powerful magnetic outrunner rotor.
- Suitable for all T-REX 250 class machines.

Specification:

Input voltage: DC7.4-11.1V 2-3cell Li-Po Max continuous current: 16/24A(5sec)
Max output power: Approx. 170w/250W(5sec) KV value: 3600KV
Dimension: spindle 2.5xΦ25.5x22.4mm Weight: Approx. 33.5g

Accessories:

- Socket button head screw(M2.5X5mm) x 2
- ALIGN standard 3mm gilt terminal x 3 set
