BL3660 3.5T 3800KV 1200W 4 Poles Sensorless Brushless Motor for 1/16 1/18 RC Car

Availability: In stock, usually dispatched in 1 business day

  • Price:$25.98
  • Price in reward points: 260 Reward Points: 3
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $25.46 $24.94 $24.16 $23.12 Contact US
Quantity:

BL3660 3.5T 3800KV 1200W 4 Poles Sensorless Brushless Motor for 1/16 1/18 RC Car

Features:

- 4 poles 12 slot high torque motor
- CNC 6061 T6 aluminum heat sink
- Copper coil
- High speed ABES5 bearing
- For 1/16 1/18 brushless car,can use M3/M4 screw
- Can replac /move the rotor
- 0.35mm rotor

Specification:
- Power: 1200W
- Maximum voltage: <13V
- Maximum current:92A
- Rotor: 4 poles
- Input current: 2.8A
- Resistance: 0.0083
- KV(RPM/V): 3800
- Maximum Rpm: 50000
- Length: 55mm
- Diameter: 36mm with fins
- Weight: 195g
- Shaft: 5mm
- Maximum extension axis length: 17mm
- Interface: 4.0mm gold

Package included:
- 1 x Brushless Motor
