• BN-180 Ublox M8030KT DC2.8-6.0V GPS Module with Antenna for FPV Multicopter

BN-180 Ublox M8030KT DC2.8-6.0V GPS Module with Antenna for FPV Multicopter

Availability: In stock, usually dispatched in 1 business day

  • Price:$19.80
  • Price in reward points: 198 Reward Points: 2
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $19.40 $19.01 $18.41 $17.62 Contact US
Quantity:

BN-180 Ublox M8030KT DC2.8-6.0V GPS Module with Antenna for FPV Multicopter

Specifications:

- Dimension: 18*18*6mm
- Power supply: DC 2.8-6.0V
- Power consumption: 50mA@5V
- Receive format: GPS, GLONASS, Galileo, BeiDou, QZSS and SBAS
- Receive channel: 72
- Receive sensitivity: -167dbm for tracking; -148dbm for acquisition
- Location time: Cold start 26S; Warm start 25S; Hot start 3S
- Horizontal precision: 2.0m at open space
- Output frequency: 1hz~10hz, default 1Hz
- Speed precision: 0.1m/s(without aid)
- Acceleration precision: 0.1m/s2(without aid)
- Dynamic features: Max.height 18,000m; Max.speed 515m/s; Max.acceleration 4g
- UART port: UART communication: TXDA/RXDA, support speed ratio 4800bps~115200bps, default 9600bps
- Work temperature: -40~+85°C

Package included:
- 1* BN-180 GPS module
