Bside-ACM02 Plus Digital AC Current Measuring AC Voltage Temperature Clamp Meter

Availability: In stock, usually dispatched in 1 business day

  • Price:$28.35
  • Price in reward points: 284 Reward Points: 3
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $27.78 $27.22 $26.37 $25.23 Contact US
Quantity:

Bside-ACM02 Plus Digital AC Current Measuring AC Voltage Temperature Clamp Meter

Features:
- It is designed according to IEC1010–1 and IEC1010–2–032 concerning safety requirements.
- Use for measure AC current,
- AC/DC voltage,resistance, capacitance,temperature, frequency, diode and circuit, etc.
- Auto/Manual range.
- Continuity test, duty cycle test & diode test.
- With a LCD display to show data
- Clamp lighting & back light.
- Data can be hold.
- Display is 3999 counts.
- Safe and professional.

Specifications:
- Display: 3999 counts
- DCV: 400m/4V/40V/400V/600±0.8%
 ACV: 400mV±0.8%,4V/40V/400V/600V±1.0%
- ACA: 4A/40A/400A/600A±2.0%
- Resistance: 400Ω/4kΩ/40kΩ/400kΩ/4MΩ±1.2%, 40MΩ±2.0%
- CAP: 50nF/500nF/5μF/50μF/100μF±4.0%
- Frequency: 50Hz/500Hz/5000Hz/50kHz/100kHz±1.0%
- Temperature: -20°C to 750°C +/-2.0%

Instruction: click here
