Current-to-Voltage Signal Module 4-20MA to 0-5V Linear Conversion
Specification:
- Module parameters
- working voltage: 9V ~ 17V
- input current: 4.00MA ~ 20.00MA
- output voltage: 0.00V ~ 5.00V /
- the control mode: 4.00MA (mA) ~ 20.00MA (mA) input is converted to the corresponding 0.00v (V) to 5.00V (volts)
- Size: (L) 26mm * (W) 23mm * (height) 10mm
- drive: no drive.
Applications: Current signal transduction voltage signal; remote data acquisition and control equipment;
the module interface:
12V: power supply positive interfaces (9V ~ 17V).
G: Power to the ground interface.
IN: Signal input interface (4.00MA ~ 20.00MA).
G: Power to the ground interface.
OUT: Signal output connector (0.00V ~ 5.00V).
G: Power to the ground interface.
Package:
1pc Current-to-Voltage Signal Module 4-20MA to 0-5V Linear Conversion
