Din Rail Mounted AC100V/110V-220V/230V/240V to DC24V 3.2A Power Supply 75W

SKU: 34553
0(0 Reviews)
Write a review(Get Thanksbuyer Points!)

Availability: In stock, usually dispatched in 1 business day

Price:$35.10
Price in reward points: 351 Reward Points: 4

Quantity	3+ units	10+ units	30+ units	50+ units	More
Price /Unit	$34.40	$33.70	$32.64	$31.24	Contact US

Buy it now Add cart

You might like

DAM3233N-0.7m USB to RS232 Adapter Cable 1-Channel USB-RS232 Converter Compatible with USB1.1/USB2.0 $28.23
DAM3232N-1.5m USB to RS485 Adapter Cable 1-Channel USB-RS485 Converter Compatible with USB1.1/USB2.0 $34.06
DAM3232N-0.7m USB to RS485 Adapter Cable 1-Channel USB-RS485 Converter Compatible with USB1.1/USB2.0 $32.31

Product details
Reviews (0)

Din Rail Mounted AC100V/110V-220V/230V/240V to DC24V 3.2A Power Supply 75W

SPECIFICATIONS

INPUT	AC100V to AC240V Universal
Voltage Range	85～264 VACselected by switch 47～63 Hz；120～370VDC
AC Current	1.6 A/115 V 0.96A/ 230 V
Efficiency	76%(DR-75-12); 80%(DR-75-24); 81%(DR-75-48)
Inrush Current	Cold start 20A/115V 40A/230V
Leakage Current	＜1mA/240VAC

PROTECTION
Over Load	105%～150%
	Protection type: Constant current limiting, recovers automatically after fault condition is removed
Over Voltage	120%~140%
	Protection type: Hiccup mode, recovers automatically after fault condition is removed
OVER TEMP.	TSW1≥85℃±5℃，
	Protection type: Shut down o/p voltage, recovers automatically after temperature goes down

ENVIRONMENT
Working Temp., Humidity	10℃～+60℃；20%～90 %RH
Storage Temp., Humidity	-20℃～+85℃；10%～95 %RH
Vibration	10～500Hz，2G 10min./1cycle, period for 60min, each along X, Y, Z axes

SAFETY
Withstand Voltage	I/P-O/P: 3KVACI/P-FG: 1.5KVACO/P-FG: 0.5KVAC
Isolation Resistance	I/P-O/P, I/P-FG, O/P-FG: 100M Ohms / 500VDC

STANDARD
Safety Standard	Design refer to UL508,TUV EN60950-1
EMC Standard	EN55011,EN55022,EN61000-3-2,-3,EN61000-4-2,3,4,5,6,8,11,ENV50204,EN55024,EN61000-6-2

OTHERS
Weight	0.6Kg
Packing	20pcs/13Kg/1.1CUFT

NOTE	1.All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25℃ of ambient temperature.
	2.Ripple & noise are measured at 20MHz of bandwidth by using a 12″twisted pair-wire terminated with a 0.1μ & 47μ parallel capacitor.
	3.Tolerance: includes set up tolerance, line regulation and load regulation.
	4.The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets EMC directives.

OUTPUT

Model	DR-75-12	DR-75-24	DR-75-48
DC Voltage	12V	24V	48V
Voltage Tolerance	±2%	±1%	±1%
Rated Current	6.3A	3.2A	1.6A
Current Range	0-6.3A	0-3.2A	0-1.6A
Rated Power	76W	76.8W	76.8W
Ripple & Noise	100mVp-p	150mVp-p	240mVp-p
DC Adjustment Range	17%	17%	10%
Setup, Rise Time	1000ms,60ms/230VAC at full load1800ms,60ms/115VACat full load
Hold Time	60ms/230VAC12ms/115VAC at full load
