DS1054Z 50MHz Digital Oscilloscope 4 Channels Analog 50MHz Bandwidth 1GSa/s Sample Rate OSC
Specification:
- BW 50MHz
- Max. Sample rate 1GSa/s (single-channel)
- 500MSa/s(dual-channel)
- 250MSa/s(four-channel)
- Max. Memory Depth 12Mpts(standard,1CH) ,24Mpts(option,1CH)
- Max. Waveform Acquisition rate 30,000 wfms/s
- Channels 4
- Trigger functions Edge,Pulse width,slope,video,pattern,Runt,Windows,Nth Edge,Delay,Time Out,Duration,setup/hold,RS232/UART,I2C,SPI
- Series Bus Decording RS232/UART,I2C,SPI
- Math functions A+B, A-B, A×B, A/B, FFT, A&&B, A||B,A ^B, !A, intg, diff, sqrt, lg, ln, exp, abs
- Auto Measurements Maximum, Minimum, Peak-Peak Value, Top Value, Bottom Value, Amplitude, Average, Mean Square Root, Overshoot, Pre-shoot, Area, Period Area, Frequency, Period, Rise Time, Fall Time, Positive Pulse Width, Negative Pulse Width, Positive Duty Cycle, Negative Duty Cycle, Delay A-B rising edge, Delay A-B falling edge,Phase A-B rising edge,Phase A→B falling edge
- Input R (1MΩ±2%)||(13 pF±3 pF)
- Display 7.0 inches TFT LCD display,800 horizontal×RGB×480 vertical pixel
- BW Limit 20MHz
- Connectivities USB HOST, USB DEVICE, LAN, Aux (TrigOut /PassFail)
- Size(W×H×D) 313.1 mm× 160.8 mm×122.4 mm
- Weight 3.2 kg ± 0.2 kg
Package included:
- 1 x Oscilloscope
- 1 x Power cable
- 1 x CD
- 1 x Probe
