DUALSKY X-Motor XM5010GB-SR Four-Rotor Brushless Gimbal Motor Outrunner for FPV Multicopter UAV

Tags: Brushless Gimbal Motor

Availability: In stock, usually dispatched in 1 business day

  • Price:$71.88
  • Price in reward points: 719 Reward Points: 7
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $70.44 $69.00 $66.85 $63.97 Contact US
Quantity:

DUALSKY X-Motor XM5010GB-SR Four-Rotor Brushless Gimbal Motor Outrunner for FPV Multicopter UAV

Features:
- Ultra-thin design
- Sealing structure, dust-proof and waterproof (IP45)
- One-piece design by CNC for rotor and shaft, good in strength and light weight
- For FPV, handheld gimbal
- High torque, special winding head
- Low working current, suitable for long time working environment
- Stator can be disassembled for ease of maintenance (50mm or above)
- Over-sized bearing, very good control of vibration
- Light weight design
- New stator outlet plate, easy for welding line
- For 3 axis gimbal, especially the demand of YAW axis

Specifications:
- Model NO.:  XM5010GB-SR
- Diameter: 49mm
- Height: 30.8mm
- Weight: 117g
- Internal resistance: 9.3 Ω
- Configuration: 24N26P
- Camera range:   MSLR cameras
- Mounting spacing (bottom): M3, 25 / 25mm
- Mounting spacing (top): M2.2, 12 / 12mm

Package included:
- 1* DualSky XM5010GB-SR motor
