DUALSKY XM5015TE-6 Brushless Outrunner Motor 390RPM/V for Multi Rotor Multicopter

28 poles. High torque. High efficiency. Specifically designed for Multi Rotor. It also can be used for Remote control aircrafts. KV:390RPM/V.

Specifications:

- KV:  390RPM/V
- Weight: 160g
- Diameter:  50mm
- Length:  36.5mm
- Diameter of Shaft:  6mm
- Mounting holes pitch:  19/25mm
- Slots,Poles:  24, 28
- Idle Current(Io) @10V:  1A
- Resistance(Ri):  59mOhm
- Cruising power[8 mins]:  428.92W
- Bursts current[15s]:  35.13A
- Peak power[15s]:  779.85W
- Recommended ESC:  XC6018BA
- Setup 1 (No. of Cell, Prop.):  6S, up to 16x5
- Max. weight of 4-rotor copter:  4.29kg
- Max. weight of 3D models: 1.43kg
- Memo:  4KG 4-rotor copters, 30E 3D airplanes
