• Fatshark Attitude V2 FPV AIO Goggle Video Glasses

Fatshark Attitude V2 FPV AIO Goggle Video Glasses

Availability: In stock, usually dispatched in 1 business day

  • Price:$519.68
  • Price in reward points: 5197 Reward Points: 52
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $509.29 $498.89 $483.30 $462.52 Contact US
Quantity:

Fatshark Attitude V2 FPV AIO Goggle Video Glasses

Description:
- The Fat Shark Attitude V2 is the best First Person View / FPV headset from the Fat Shark line-up. The Smaller and lighter Attitude video goggles are packed with the latest technology and features to deliver outstanding performance from Fat Shark. The Attitude video goggles were designed for first person view flights from either planes or multi rotor craft, with a 35 degree FOV display delivering the perfect balance between compact pixel density clarity and large screen immersion in the flight. The Attitude V2 video goggles have the polarised backlight technology seen in the Dominator video goggles for crisp and vibrant colours, however the Attitude V2 goggles have inbuilt adjustable IPD not seen on the dominator’s, this means that you can quickly adjust the focus for each eye without the need to insert any additional lens. However if required additional lenses can be inserted ordered and fitted to allow you total control and customisation to your needs.

- The head tracker is also built into the Attitude V2; this is the latest generation of MIG tracker (V5) with new algorithms refined for a drift free precision head tracking flight. The integrated 5.8 GHz receiver module is latest generation which sees an improvement in sensitivity and an increase in range by a dramatic 40% over the previous models of fat Shark video goggles. The improved high-pass filtering added to the Attitude V2 video goggles make it resistant to 433 MHz, 2.4 GHz & UHF radio interference.The improvements to the electronics were not the only ones made, there have been exterior changes to the Attitudes’, they now come with a rubberised velvety texture covering, tactile motion IPD sliders, secured rubber eye cups and a thinner head strap, overall these video goggles look and feel great with outstanding optics!

Interface:
- 3.5mm AV in/out port.
- 3.5mm stereo earphone port.
- PS/2 DIN head tracker data port.
- Operating Frequencies:5740, 5760, 5780, 5800, 5820, 5840, & 5860 MHz

Headset Specifications:
Field of view(FOV) 35°diagonal (Image size: 1.3m @ 2m) Inter-pupillary distance(IPD) 59 – 69 mm (adjustable)
User Controls Channel selection/ head tracker reset Power supply 7 - 13 V (2S/3S supply)
Battery 7.4V 1000mAh (not included) Supports optional dioptre lens inserts -2, -4, -6 dpt
Weight 150g Head Tracker MIG V5
(magnetic, inertial and gyro sensors)
Power consumption
(@7.4V nominal)
300mA wireless
150mA direct mode (RX off)
Antenna External dipole
(RX is circular polarized compatible)
Audio Stereo (requires adjustable volume earphone accessory)
Display Full colour LCD LED backlit Kopin Cyber Display 922,000 pixels binocular display (640 X 480 VGA) NTCS/PAL auto selecting.

Transmitter Specifications:

Power supply 7-13 V (2S/3S supply) Power rating 310mA @7.4V
TX power 250mW Antennae External dipole (circular polarized compatible)
Size 55x26x11mm Weight 22g (w/antenna)

Download Manual
Download Datasheet

Package Included:
- 1 x Fat Shark Attitude V2 headset (with integrated 5.8 GHz RX and Head Tracker V5)
- 1 x 250 mW 7 channel 5.8 GHz Transmitter with 600 TVL Camera
- 1 x EzUHF data cable
- 1 x Protective carry case
- 1 x Lens cleaner cloth
- 1 x Filtered balance lead adapter
- 2 x 3dBi 5.8 GHz antennas
- 1 x 3m AV cable
- 1 x Futaba data cable
