GPS Module for OK6410/FL2440 ARM Development Board
  • GPS Module for OK6410/FL2440 ARM Development Board

  • SKU:28316
    (0 reviews)   Write a review(Get Thanksbuyer Points!)
  • Availability: In Stock     Reward Points: 5
  • Price:$48.90
  • Price in reward points: 489
  • Buy more, save more
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $47.92 $46.94 $45.48 $43.52 Contact US

GPS Module for OK6410/FL2440 ARM Development Board

Items include:
- 1x GPS Module
- 1 x Antenna
- 1x 20P data cable or serial port cable

Chip Set: SiRF StarⅢ Frequency: L1, 1575.42 MHz
C/A code: 1.023 MHz chip rate Channels: 20
Sensitivity: -159 dBm Position: 5 meters, 2D RMS, WAAS enabled
Velocity: 0.1 m/s Time: 1us synchronized to GPS time
Default Datum: WGS-84 Reacquisition: 0.1 sec., average
Hot start: 1 sec., average Warm start: 38 sec., average
Cold start: 42 sec., average Altitude: 18,000 meters (60,000 feet) max
Velocity: 515 meters /second (1000 knots) max Acceleration: Less than 4g
Jerk: 20m/S3 Main power input: 5V±0.5V DC
Currency: ≈60mA,≤100mA Module Dimension: 61mm×49mm×17mm
