Hantek DSO1152S Full Isolation 5.6 inch Color LCD Handheld Oscilloscope Multimeter 150MHz 1GSa/s 1M Memory Depth
Feature:
- Isolated level: 1000V CATII, 600V CATIII.
- High Bandwidth 150MHz Oscilloscope, 1GSa/s sample rate, 6000 Counts DMM with analog bargraph and data recorder.
- 1M Memory Depth.
- High Refresh Rate (2500 frames).
- Large 5.6 inch TFT Color Display, High Resolution(640*480), Dual-Window Design --More clear, More detailed.
- One-touch automatic setup optimizes the position, range, timebase, and triggering to assure a stable display of virtually any waveform.
- Easy-to-use pop-up menu with built-in multi-language help system.
- 32 Automatic Measurements.
- Waveform Math: Add, Subtract, Multiply, and Divide.
- Store and recall over.
- Automatic cursor tracking measurements.
- XY Mode.
- Built-in FFT function converts a time-domain signal into its frequency components to measure harmonic content and distortion in systems.
- Waveform Recorder to collect/replay input waveforms from CH1 and CH2 with a maximum record length of 1000 frames.
- Pass-Fail function compares a stored waveform to an unknown input.
- Average Mode for smoothing waveforms.
- Square Wave Output (2V, 1kHz) for probe adjustment.
- USB Host/Device 2.0 full-speed interface, support removeable disk, LAN Option, easy to control by PC or long-distance.
- Dimensions (mm):240(L)x165(W)x50(H), be carried easily.
Package included :
