• HYELEC MS2203 LCD Professional Multifunction 3-Phase Clamp Meter Power Factor Correction USB True-RMS 4 Wire Testing

HYELEC MS2203 LCD Professional Multifunction 3-Phase Clamp Meter Power Factor Correction USB True-RMS 4 Wire Testing

Availability: In stock, usually dispatched in 1 business day

  • Price:$166.92
  • Price in reward points: 1669 Reward Points: 17
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $163.58 $160.24 $155.24 $148.56 Contact US
Quantity:

HYELEC MS2203 LCD Professional Multifunction 3-Phase Clamp Meter Power Factor Correction USB True-RMS 4 Wire Testing

Specifications:
AC Voltage: 0.1~600V  ±(1.2%+5)
AC Current: 0.1A~1000A ±(2.0%+5)
Active Power: 0.1kW~600kW  ±(3.0%+5)
Apparent power: 0.1kVA~600kVA ±(3.0%+5)
Reactive power: 0.1kVAr~600kVAr:  ±(3.0%+5)
Power Factor: 0.3~1 ±(2.0%+2)
Active Energy: 0.001kWh~10000kWh  ±(3.0%+2)
Frequency: 20Hz~1000Hz  ±0.5%

Feature:
Auto Power Off  √
Auto Ranging  √
Max/min  √
Data Hold  √
Display Back Light  √
Jaw opening  R50mm/2.0”
Data logging And recall  28 groups
LBD  Low Battery indication
True RMS True Root Mean Square Measurement
Display  9999 counts
Rs232 Interface  √

General:
Power Supply  4 x 1.5V AA Battery(Not Included)
Category  CE CAT .III 600V RoHS
Package size: 33 * 22 * 6cm / 13.2 * 8.8 * 2.4in
Package weight: 1535g / 3.4 lb

Package list
1 * HYELEC MS2203 3-Phase Clamp Meter
1 * Portable Bag
1 * Test Probe
4 * Test Clip
1 * Rs232 Interface Cable
1 * CD
1 * English Instructions
Battery(Not Included)
