Large Power 2W Wireless Audio Video Monitor Module Receiver Transmitter Combo RX TX A Set
TX module Specification:
- Brand: rfav
- Model: TX6722
- Unit: piece
- Operating frequency: 2.4GHz
- 2 sets of frequencies 8 channels available, easy to avoid interference frequency:
Ch1 2414/2490MHz Ch2 2432/2510MHz
Ch32450/2390MHz Ch4 2468/2370MHz
- Modulation: FM Broadband modulation
- Power: 2W
- Operating voltage: 5V
- Current consumption: 600-800mA
- Dimensions: 45mm*28mm*10mm
- Communication: empty launch distance 2000-3000M
RX module Specification:
- Brand: rfav
- Model: TX6788
- Unit: piece
- Operating frequency: 2.4GHz
- 2 sets of frequencies 8 channels available, easy to avoid interference frequency:
Ch1 2414/2490MHz Ch2 2432/2510MHz
Ch32450/2390MHz Ch4 2468/2370MHz
- Modulation: FM Broadband modulation
- Working sensitivity: -93dBm
- Operating voltage: 5V
- Current consumption: 150mA
- Dimensions: 45mm*30mm*4.8mm
- Build in phase locked loop frequency, high stability
- Low noise leak, can pass FCC and CE(R&TTE) wireless authentication
- Can direct output audio video signal
- STM installation, convenient for users to use
