MASTECH MS5900 Motor 3-phase Rotation Indicator Meter

Availability: In stock, usually dispatched in 1 business day

  • Price:$30.45
  • Price in reward points: 305 Reward Points: 3
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $29.84 $29.23 $28.32 $27.10 Contact US
Quantity:

MASTECH MS5900 Motor 3-phase Rotation Indicator Meter

MASTECH founded in 1987, is the world's largest instrument manufacturer, is the world's leading provider of electronic measuring instruments, one of the test instrumentation industry is well-known brand is recognized by the national brand-name high-tech enterprises in Guangdong Province products, electrical instrumentation industry, the main drafter of the national standard.

Main Features:
- Determine the Motor Connection
- Non-Contact Rotary Field Indication
- Determine Rotary Field Direction
- Standalone direction indicator
- Wireless

Specifications:
-  Operating Temperature: 0 °C ~ 40 °C
-  Operating Altitude: 2000 m
- Pollution Degree: 2
- Type of Protection: IP 40
- Humidity 15 % to 80 %
- Electrical Safety:
- Meets DIN VDE 0411, IEC 61010 DIN,
- VDE 0413-7, EN 61557-7, IEC 61557-7
- Maximum Operating Voltage (Ume): 400 V AC for all ranges
- Protection Level: CAT III, 600 V
- Battery: 6F22/9V (Not Included)
- Current Consomption: max 20 mA
- Nominal Voltage Rotary Direction: 1 to 400 V AC
- Nominal Voltage Phase Indication: 120 to 400 V AC
- Frequency Range (fn): 2 to 400 Hz
- Test Currents (In per phase): less than 3.5 mA
- Frequency Range (fn): 2 to 400 Hz
- Determine the Motor Connection
- Nominal Test Voltage (Ume): 1 to 400 V AC
- Nominal Test Currents (In per phase): less than 3.5 mA

Package Including:
- 1 x MS5900 motor phase rotation indicator Meter
- 1 x Tool Box
- 3 x Alligator clips
- One set of Probe
