MLX90614ESF-DCI/DS Digital Non-contact Infrared Temperature Sensor IIC Long Range Communicate Sensor
Description:
- Advanced low-noise amplifier used in the signal conditioning chip, a 17-bit ADC and powerful DSP unit, which Achieve high accuracy of temperature measurement. - Calculation and stored in RAM and the environment temperature object can realize temperature 0.02 o C of the resolution of the data, and It is through the two-lane standard SMBus output (0.02 ° C resolution) or 10-bit PWM output.
- The MLX90614 object temperature range of -40 ... 125 º C ambient temperature and -70 ... 382.2 º C, the factory calibration.
- The chip calculated temperature is the average temperature of all objects in perspective within the scope of the sensor the MLX90614 room temperature within the standard accuracy of
- High accuracy of ± 0.5 º C. In order to meet the requirements of medical applications MLX90614 can also be provided in the body temperature within ± 0.1 º C.
- Built-in Niefei Er lens, daylight immune-free calibration. The DCI series is currently the highest level, with a gradient of temperature compensation, the object distance of up to 12:1
Product Features
- Small size, low cost
- Ease of integration
- Wide temperature range of factory calibration:
-40 ... +125 º C operating temperature
-70 ... +380 º C target temperature.
- According to the high accuracy of 0.5 ° C wide temperature range.
- (When the environment and the object temperature 0 .. +50 ° C)
- Ultra-high precision calibration (medical grade)
- 0.02 ° C temperature resolution
- Single sensor or sensing region
- Support the SMBus inputs and outputs standard (default)
- Compatible with pulse width modulation (PWM) output mode
- Multi-sensor region - can support up to 100 from the device address
- 3V and 5V operation to choose from (slave address)
- Plus a simple circuit can be used for 8 to 16V operating voltage
- Energy-saving shutdown mode
- A variety of package options to apply to different application areas
- Vehicle level of standards
Application:
- High-precision non-contact remote temperature
- Comfort temperature sensing, can be used in automotive air conditioning systems
- Household, industrial air conditioning temperature sensor adjustment
- Windshield defrost system
- Automotive vision dead space probe
Package Including
- 1 x infrared temperature sensor * 1pcs
