• MP-503 10-1000ppm Gas Detection Sensor Module Alcohol Smoke Detection

MP-503 10-1000ppm Gas Detection Sensor Module Alcohol Smoke Detection

Availability: In stock, usually dispatched in 1 business day

  • Price:$15.67
  • Price in reward points: 157 Reward Points: 2
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $15.36 $15.04 $14.57 $13.95 Contact US
Quantity:

MP-503 10-1000ppm Gas Detection Sensor Module Alcohol Smoke Detection

Description:

- working voltage: DC5V
- working current: 60mA
- loop voltage: less than 5V
- output voltage: 0-5V range (resistance ratio corresponding to the concentration of output)
- load resistance: 10K (adjustable)
- detection concentration range:
MP-501:10-1000ppm (alcohol, smog)
MP-502:1-50ppm (formaldehyde, toluene, benzene, acetone, alcohol system gas)
MP-503:10-1000ppm (alcohol, smog)
MP-901:10-1000ppm (alcohol, hydrogen, Jia Wan)
- clean air voltage: less than 1.5V
-  sensitivity: 3%
- the response time: less than 10S (pre 3-5 minutes)
- recovery time: less than 30S
- power consumption: less than 300mW
- working temperature: -10~50 (nominal temperature 20)
- working humidity: 95%RH (nominal humidity 65%RH)
- service life: 5 years
- size: 35mm x 40mm x 18mm
- weight: 10g
