OCROBOT HoneyBee Development Board  Fully Compatible with Arduino & Zigbee

Introduction:
- Integrate 802.15.4 protocol wireless module, support any wireless module based on this protocol, including ZigBee,MAC/6LoWPAN, and RF4CE
- Support almost all arduino wireless sensor network operation system, like Contiki、TinyOS、Nank-RK, also support Atmel BitCloud Zigbee protocol stack



Features:
- Built-in Zigbee wireless module
- Built-in lipo battery control module
- With 128K Flash and 16K SRAM.

Specifications:
- MCU: ATMEGA128RFA1
- Working voltage: 3.3V
- Input voltage: DC7-18V, AC7-12V
- Digital IO pin: 35pcs
- PWM pin: 8pcs
- Analog I/O pin: 8pcs(0-1.8V)
- FLASH: 128K
- SRAM: 16K
- EEPROM: 4K
- Clock rate: 16MHZ
- Emission rate: +3.5dBm
- Receive sensitivity: -100dB
- Max.lipo charging current: 500mA

Compatibility:
- All IO only support 3.3V level
- Compatible with current arduino library.
