PIX ULBOX NEO-7M GPS Module High Precision for Multicopter FPV Photography

PIX ULBOX NEO-7M GPS Module High Precision for Multicopter FPV Photography

Description:
- The new version GPS data cable interface is DF13 gluey shell, has lock up buckle function. If you don't want it locked,  please chop off the triangle lock catch
- If it can not match with old version socket, please cut the protrude part open by knife
- This GPS wires are all terminal interface of DF13, if you change to gluey shell, you need to use it with DF13 gluey shell.
- Built in electric compass version can be used at APM 2.5/ 2.6, compatible with PIX flight control
- 2.5 needs to be cut off built in electric compass jumping cable

GPS cable definition:
- Red vcc        Black gnd
- Green RX     Yellow  TX

Compass cable definition:
- Orange  SCL    White  SDA

U-BLOX NEO-7M
- NEO-7 series is the newest version among u-blox independent GPS/ GNSS module.
- NEO-7 series has largest sensitivity while maintaining the lowest system consumption
- NEO-7N is easy for RF integration

- Receiver type:
56 channel u-blox 7 engine
GPS L1 C/A GLONASS L1 FDMA
QZSS L1 C/A
Hardware support: Galileo E1B/C, Compass
SBAS: WAAS, EGNOS, MSAS

- Max updating speed rate reachs 10Hz
- Precision GPS/ GLONASS:
Positioning  2.5 m CEP / 4.0 m
SBAS 2.0 m CEP / n.a.

- For GPS/ GLONASS:
Cold start up:  29 s / 30 s
Assistive start up: 5 s / n.a.
Recollection:  1 s / 3 s

- Sensitivity GPS/ GLONASS
Tracking : –162 dBm / –158 dBm
Cold start up : –148 dBm / –140 dBm
Warm start up: –148 dBm / –145 dBm

- Assitance:
AssistNow Online
AssistNow Offline
AssistNow Autonomous
Meet OMA SUPL and 3GPP specification

- Oscillator:  TCXO (NEO-7N), Ordinary crystal  (NEO-7M)
- RTC crystal: built in
- Anti inteference: CW detection and clearance
- Storage: onboard ROM (NEO-7M) or Flash (NEO-7N)
- Antenna support: active and passive
