PIXHAWK Autopilot 32Bits Flight Controller Driver for Multirotors Fixed-wing Copters Replace of PIX PXI PX4

Features
- 32 bit ARM Cortex M4 Processor running NuttX RTOS
- 14 PWM / Servo outputs (8 with failsafe and manual override, 6 auxiliary, high-power compatible)
- Abundant connectivity options for additional peripherals (UART, I2C, CAN)
- Integrated backup system for in-flight recovery and manual override with
- dedicated processor and stand-alone power supply
- Backup system integrates mixing, providing consistent autopilot and manual
- override mixing modes
- Redundant power supply inputs and automatic failover
- External safety switch
- Multicolor LED main visual indicator
- High-power, multi-tone piezo audio indicator
- microSD card for long-time high-rate logging

Specifications
- 32bit STM32F427 Cortex M4 core with FPU
- 168 MHz
- 256 KB RAM
- 2 MB Flash
- 32 bit STM32F103 failsafe co-processor
- ST Micro L3GD20H 16 bit gyroscope
- ST Micro LSM303D 14 bit accelerometer / magnetometer
- MEAS MS5611 barometer

Interfaces
- 5x UART (serial ports), one high-power capable, 2x with HW flow control
- 2xCAN
- Spektrum DSM / DSM2 / DSM-X® Satellite compatible input
- Futaba S.BUS® compatible input and output
- PPM sum signal
- RSSI (PWM or voltage) input
- I2C®
- SPI
- 3.3 and 6.6V ADC inputs
- External microUSB port

Power System and Protection
- Ideal diode controller with automatic failover
- Servo rail high-power (up to 10V) and high-current ready (10A +)
- All peripheral outputs over-current protected, all inputs ESD protected
- Monitoring of system and servo rails, over current status monitoring of peripherals

Dimensions
- Weight: 38g (1.31oz)
- Width: 50mm (1.96")
- Thickness: 15.5mm (.613")
- Length: 81.5mm (3.21")
