PULSO U22L 2217 KV760 12N14P Brushless Motor for Multicopter FPV Quadcopter
  • PULSO U22L 2217 KV760 12N14P Brushless Motor for Multicopter FPV Quadcopter
  • PULSO U22L 2217 KV760 12N14P Brushless Motor for Multicopter FPV Quadcopter
  • PULSO U22L 2217 KV760 12N14P Brushless Motor for Multicopter FPV Quadcopter

  • SKU:26798
    (0 reviews)   Write a review(Get Thanksbuyer Points!)
  • Availability: In Stock     Reward Points: 5
  • Price:$49.13
  • Price in reward points: 491
  • Buy more, save more
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $48.15 $47.16 $45.69 $43.73 Contact US

PULSO U22L 2217 KV760 12N14P Brushless Motor for Multicopter FPV Quadcopter

Specifications:
- Stator Dia.: 22mm
- Stator thickness: 17mm
- KV: 760
- Slot Number: 12
- Poles: 14
- Rotor Max. Diameter: 27.7mm
- Shaft Dia.: 3.17mm
- Motor length: 28mm
- Botton mount pitch: 19mm
- Weight: 82g(with cable)


Model No Kv Configuration Wind Stator(mm) Rotor(mm) Shaft(mm) Weight(g)
Dia. Height Dia. Length Dia. Length
U22M/785 785 12N/14P 34Δ 22 12 28 22.7 3.17 28.8 49
U22M/740 740 12N/14P 36Δ 22 12 28 22.7 3.17 28.8 49
U22L/1180 1180 12N/14P 16Δ 22 17 28 27.7 3.17 33.8 65
U22L/870 870 12N/14P 20Δ 22 17 28 27.7 3.17 33.8 65
U22L/760 760 12N/14P 22Δ 22 17 28 27.7 3.17 33.8 65
U22XL/940 940 12N/14P 16Δ 22 21 28 31.7 3.17 37.8 75
U22XL/760 760 12N/14P 20Δ 22 21 28 31.7 3.17 37.8 75
