T-MOTOR NAVIGATOR MN4010 475KV 540W 4-8S Brushless Electric Motor for Quad/Hexa/Octa copter
  • T-MOTOR NAVIGATOR MN4010 475KV 540W 4-8S Brushless Electric Motor for Quad/Hexa/Octa copter
  • T-MOTOR NAVIGATOR MN4010 475KV 540W 4-8S Brushless Electric Motor for Quad/Hexa/Octa copter
  • T-MOTOR NAVIGATOR MN4010 475KV 540W 4-8S Brushless Electric Motor for Quad/Hexa/Octa copter
  • T-MOTOR NAVIGATOR MN4010 475KV 540W 4-8S Brushless Electric Motor for Quad/Hexa/Octa copter
  • T-MOTOR NAVIGATOR MN4010 475KV 540W 4-8S Brushless Electric Motor for Quad/Hexa/Octa copter
  • T-MOTOR NAVIGATOR MN4010 475KV 540W 4-8S Brushless Electric Motor for Quad/Hexa/Octa copter
  • T-MOTOR NAVIGATOR MN4010 475KV 540W 4-8S Brushless Electric Motor for Quad/Hexa/Octa copter
  • T-MOTOR NAVIGATOR MN4010 475KV 540W 4-8S Brushless Electric Motor for Quad/Hexa/Octa copter

  • SKU:27057
    (0 reviews)   Write a review(Get Thanksbuyer Points!)
  • Availability: Out of Stock     Reward Points: 6
  • Price:$64.55
  • Price in reward points: 646
  • Buy more, save more
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $63.26 $61.97 $60.03 $57.45 Contact US

Tiger T-Motor Navigator Series High End MN4010 475KV 3-6S Brushless Motor for Quadcopter Hexacopter















Specifications:
KV.................................................................................................................475
Configu ration....................................................................................18N24P
Stator Diameter.....................................................................................40mm
Stator Length.........................................................................................10mm
Shaft Diameter........................................................................................4mm
Motor Dimensions(Dia.*Len).............................................Φ44.5×30.5mm
Weight (g)..................................................................................................110g
ldle current(10)@10v(A)..........................................................................0.8A
No.of Cells(Lipo)......................................................................................4-8S
Max Continuous current(A)180S.............................................................30A
Max Continuous Power(W)180S.........................................................540W
Max. efficiency current...............................................................(4-11A)>82%
internal resistance................................................................................98mΩ
