T-Motor Tiger Disk Brushless Motor MT3515 650KV 5S-6S for Multi-rotor Quad Hexa OctoCopter
  • T-Motor Tiger Disk Brushless Motor MT3515 650KV 5S-6S for Multi-rotor Quad Hexa OctoCopter
  • T-Motor Tiger Disk Brushless Motor MT3515 650KV 5S-6S for Multi-rotor Quad Hexa OctoCopter
  • T-Motor Tiger Disk Brushless Motor MT3515 650KV 5S-6S for Multi-rotor Quad Hexa OctoCopter
  • T-Motor Tiger Disk Brushless Motor MT3515 650KV 5S-6S for Multi-rotor Quad Hexa OctoCopter
  • T-Motor Tiger Disk Brushless Motor MT3515 650KV 5S-6S for Multi-rotor Quad Hexa OctoCopter
  • T-Motor Tiger Disk Brushless Motor MT3515 650KV 5S-6S for Multi-rotor Quad Hexa OctoCopter

  • SKU:27277
    (0 reviews)   Write a review(Get Thanksbuyer Points!)
  • Availability: Out of Stock     Reward Points: 8
  • Price:$79.99
  • Price in reward points: 800
  • Buy more, save more
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $78.39 $76.79 $74.39 $71.19 Contact US

T-Motor Tiger Disk Brushless Motor MT3515 650KV 5S-6S for Multi-rotor Quad Hexa OctoCopter



Specifications:

KV................................................................................................................650
Configu ration....................................................................................12N14P
Stator Diameter....................................................................................35mm
Stator Length........................................................................................15mm
Shaft Diameter.......................................................................................5mm
Motor Dimensions(Dia.*Len)..............................................Φ42.5×38mm
Weight (g)................................................................................................188g
ldle current(10)@10v(A).........................................................................1.2A
No.of Cells(Lipo).....................................................................................3-6S
Max Continuous current(A)180S............................................................35A
Max Continuous Power(W)180S........................................................650W
Max. efficiency current............................................................(10-20A)>79%
internal resistance................................................................................49mΩ
