Tiger T-Motor Navigator Series High End MN 3110 470KV 3-6S Brushless Motor for Octocopter Hexacopter



























Specifications:
KV............................................................................................................470
Configu  ration...............................................................................12N14P
Stator Diameter................................................................................31mm
Stator Length....................................................................................10mm
Shaft Diameter...................................................................................4mm
Motor Dimension(Dia.*Len).........................................Φ37.7×28.5mm
Weight(g)...............................................................................................80g
ldle current(10)@10v(A).....................................................................0.3A
No.of Cells(Lipo).................................................................................3-6S
Max Continuous current(A)180S.......................................................15A
Max Continuous Power(W)180S....................................................330W
Max. efficiency current............................................................(2-8A)>84%
internal resistance.........................................................................135mΩ
