Tiger T-Motor Navigator Series High End MN 3110 780KV 3-6S Brushless Motor for Octocopter Hexacopter



























Specifications:
KV..............................................................................................................780
Configu-ration.................................................................................12N14P
Stator Diameter..................................................................................31mm
Stator Length......................................................................................10mm
Shaft Diameter.....................................................................................4mm
Motor Dimension(Dia.*Len)...........................................Φ37.7×28.5mm
Weight(g).................................................................................................80g
ldle current(10)@10v(A)......................................................................0.4A
No.of Cells(Lipo)..................................................................................3-6S
Max Continuous current(A)180S........................................................26A
Max Continuous Power(W)180S....................................................481W
Max. efficiency current..........................................................(3-10A)>81%
internal resistance............................................................................71mΩ
