Tiger T-Motor Navigator Series High End MN4012 480KV 4-8S Brushless Motor for Octocopter Hexacopter
  • Tiger T-Motor Navigator Series High End MN4012 480KV 4-8S Brushless Motor for Octocopter Hexacopter
  • Tiger T-Motor Navigator Series High End MN4012 480KV 4-8S Brushless Motor for Octocopter Hexacopter
  • Tiger T-Motor Navigator Series High End MN4012 480KV 4-8S Brushless Motor for Octocopter Hexacopter
  • Tiger T-Motor Navigator Series High End MN4012 480KV 4-8S Brushless Motor for Octocopter Hexacopter
  • Tiger T-Motor Navigator Series High End MN4012 480KV 4-8S Brushless Motor for Octocopter Hexacopter
  • Tiger T-Motor Navigator Series High End MN4012 480KV 4-8S Brushless Motor for Octocopter Hexacopter
  • Tiger T-Motor Navigator Series High End MN4012 480KV 4-8S Brushless Motor for Octocopter Hexacopter
  • Tiger T-Motor Navigator Series High End MN4012 480KV 4-8S Brushless Motor for Octocopter Hexacopter

  • SKU:25119
    (0 reviews)   Write a review(Get Thanksbuyer Points!)
  • Availability: In Stock     Reward Points: 8
  • Price:$84.23
  • Price in reward points: 842
  • Buy more, save more
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $82.55 $80.86 $78.33 $74.96 Contact US

T-Motor Navigator Series MN4012 480KV 4-8S  Outrunner Brushless Motor for Quadcopter Hexacopter Multi-copter















Specifications:
KV...............................................................................................................480
Configu ration..................................................................................18N24P
Stator Diameter..................................................................................40mm
Stator Length......................................................................................12mm
Shaft Diameter.....................................................................................4mm
Motor Dimensions(Dia.*Len)..........................................Φ44.7×32.5mm
Weight (g)...............................................................................................134g
ldle current(10)@10v(A).......................................................................1.3A
No.of Cells(Lipo)..................................................................................4-8S
Max Continuous current(A)180S.........................................................29A
Max Continuous Power(W)180S.....................................................870W
Max. efficiency current...........................................................(4-11A)>79%
internal resistance.............................................................................57mΩ
