UBLOX LEA-5H GPS Module Built in Antenna 2.5m Accuracy

Description:

- Brand new ULBOX LEA-5H GPS module with 2.5m accuracy(official data,and actually 10-30M)
- Defualt 6.02 hardware
- 6 pin port(4 pin with defined--empty GND TX RX VCC empty)
- GND black,VCC Red
- Built in high sinal antenna
- Built in back up battery
- Defualt ublox 38400 4hz output,APM ACM version can distinguished it as ublox GPS

Specfication:
- 50 Channel u-blox engine,
- Location time:<1 second
- 160dBm SuperSense tracking sensitivity
- with Kickstart function
- Support AssistNow Online and AssistNow Offline and A-GPS service
- GPS、GALILEO、SBAS(WAAS、EGNOS、MSAS、GAGAN) Engine
- 0 4Hz positioning update speed
- Receiver type: 50 Channel u-blox 5 engine
- GPS L1 C/A code
- GALILEO L1 SBAS:WAAS、EGNOS、MSAS、GAGAN

Port details:
- 1 UART port
- 1 USB V2.0,full speed 12Mbit/s
- 1 DDC port
- 1 SPI port

Accuracy:
- precision positioning:2.5Mcep
- SBAS :2.0mCEP
- Power: 120mW @ 3.0V
- Back up battery:1.3V -4.8V
- Sensitivity:-160dBm
- Tracking:-160dBm
- A-GPS support AssistNow Online and AssistNow Offline
- working temperature: -40℃- +85℃
- storage temperature:-40℃- +85℃
- Limited speed:515m/s(1000 byte)
