UT202A DC Voltage AC Current Handheld Clamp LCD Digital Multimeter Voltmeter Ammeter Ohmmeter Ohm Tester

UT202A DC Voltage AC Current Handheld Clamp LCD Digital Multimeter Voltmeter Ammeter Ohmmeter Ohm Tester

Description:
UT202A is a stable, secure, and reliable 3 1/2 digit clamp meter. Whole circuit design to LSI double integral A / D converter as the core, the whole range of overload protection circuit, unique design makes it the superior performance of a dedicated electrical instruments. It can be used to measure the DC voltage, AC current, resistance, diodes, circuit continuity and so on.

Features
- Display Count: 2000
- Compact size AC clamp meter, up to 600 amps
- Jaw Capacity: 28mm
- Input Impedance for DC V: Around 10Mω
- AC/DC voltage, resistance, continuity & diode check
- Manual Range + Data hold + Maximum/Minimum value measurement
- Continuity Buzzer
- Low Battery Indicator
- Measurement update speed 3 times/second, compact and comfortable design
- Compliance with safety requirements IEC 61010, CAT III 600 V / CAT III 300 V
- Can be used for AC/DC voltage test, AC current test, electric current resistance, diode test, etc.(PS: CANNOT test DC current)
- Can be used in places such as factory, school lab, home hobby, machine repairing, etc.

Specification:
- Model: UT202A
- AC Current (A): 20A/200A/600A ±(1.5%+5)
- AC Voltage (V): 2V/20V/200V/600V ±(1.2%+5)
- DC Voltage (V): 200mV/2V/20V/200V/600V ±(0.8%+1)
- Resistance (ω): 200ω/2Kω/20Kω/200Kω/2Mω/20Mω ±(0.8%+3)
- Display: LCD, max. 1999 digits, 35.6 × 18 mm
- Power supply: 1x 9V 6F22
- MAX. Diameter for conductor: φ26 mm
- Product Net Weight: 220g
- Product Size: 210mm * 75.6mm * 30 mm
- LCD Size: 35.6mm * 18 mm

Package content:
- 1 x UT202 Multimeter (Battery is no include)
- 1 x Test lead
- 1  x Temperature probe
- 1  x Carrying bag
