LD-Power MT3508 700KV Brushless Motor for Multicopter (3-4S)

Model MT3508
Motor  Diameter 42mm
Motor Length 27mm
Stator Diameter 35mm
Stator Length 8mm
Shaft 4mm
Weight 90
Batteries 3-6Cells
No Load Current 0.4A


Voltage(V) Propeller
(inch)
Throttle Current (A) Watts(W) Thrust(G) RPM
(RPM/Min)
Efficiency (G/W)
11.1 APC 12*3.8 50% 2.6 28.86 421 3567 14.59
65% 5.4 59.94 567 4333 9.46
75% 8 88.8 789 4676 8.89
85% 11.2 124.32 956 5189 7.69
100% 15 166.5 1009 5689 6.06
APC13*4 50% 2 22.2 338 3890 15.23
65% 3.5 38.85 458 4789 11.79
75% 6 66.6 667 5554 10.02
85% 8 88.8 850 6409 9.57
100% 10.6 117.66 1020 6800 8.67
14.8 APC11*4.7 50% 4 59.2 566 4879 9.56
65% 7.2 106.56 789 5656 7.40
75% 11 162.8 1009 6442 6.20
85% 14.3 211.64 1267 6789 5.99
100% 18.3 270.84 1456 7089 5.38
APC 12*3.8 50% 4 59.2 621 5089 10.49
65% 8 118.4 901 5678 7.61
75% 12.5 185 1200 5789 6.49
85% 18.5 273.8 1456 6124 5.32
100% 22.4 331.52 1678 6578 5.06

Includes:
1 x motor
1 x prop adaptor
1 x prop holding down plate
4 x screws
