S-BS90-W White Light Camera BOSHI Illuminator Camera
Descriptions:
- Using high power LED, high efficacy and long service life
- Unique design of "Heat Dissipation Ring" can reduce LED temperature to 61°, thereby decrease LED light-decay and increase 50% lighting effect.
- Waterproof and dusty proof aluminum die-casting housing, small and durable.
- Apply to road traffic, expressway, factory zone, parking, community and school, etc
Specfications:
Item | Description | |||||||||
Lens | 6mm | 8mm | 12mm | 16mm | 25mm | |||||
Distance |
|
|
|
|
| |||||
White | 8m | 10m | 20m | 30m | 50m | |||||
Working Voltage | AC24V/DC12V | |||||||||
Current | 1000mA | |||||||||
LED Bean Angle | 60° | 45° | 30° | 15° | ||||||
Horizontal Resolution | 420TVL/480TVL/540TVL | |||||||||
CCDType | SONY 1/3" CCD | |||||||||
Pixel | PAL:752(H)×582(V) NTSC:768(H)×494(V) | |||||||||
Signal System | PAL/NTSC | |||||||||
Minimum Luminance | Color | 0.8LUX/F1.2 | ||||||||
B/W | 0LUX/F1.2 | |||||||||
S/N Ratio | ≥48dB | |||||||||
Video Output | 1.0Vp-p/75Ω | |||||||||
Auto Gain Control | Auto | |||||||||
White Balance | Auto | |||||||||
BLC | Auto | |||||||||
Exposure | Electron exposure | |||||||||
Automatic Electronic Shutter | 1/50(1/60) – 1/100000s | |||||||||
Gamma | 0.45 | |||||||||
Sync. System | Internal | |||||||||
Wavelength | 850nm | |||||||||
White | 480-500nm | |||||||||
Power Supply | DC12V/AC24V | |||||||||
Protection Level | IP-65 | |||||||||
Operating Temperature | -20℃~50℃ | |||||||||
Operating Humidity | 90%RH | |||||||||
Net/Gross Weight | 0.679KG/0.807KG | |||||||||
Packing Dimension | 125*220*105mm |
