1800W 93% ATX ETH Mining Machine Power Supply For Bitcoin Miner Antminer S7 S9

1800W 93% ATX ETH Mining Machine Power Supply For Bitcoin Miner Antminer S7 S9

Specification:
- Model: G1057-1800W
- Shell Material: Aluminum
- Size(L*W*H): 25.5*10*4.5 cm
- Cable Length: 39cm
- Power Cord Length: 1.5 Meter
- Connectors: 6 PIN * 10 Pcs
- Number of Interfaces: 10
- Fit For: S9(12.5T/13T/13.5T/14T) S7 Ant Series Mining Machine

1. Input:
- Voltage Range: AC 176~264V
- Input Rated Voltage: AC 200~240V
- Starting Inrush Current: <=80A
- Maximum Input Current: <=15A
- Efficiency: >=93%
2. Output:
- Output Rated Voltage:DC 12.25V
- Load Regulation: <=-+2%
- Linear Regulation: <=-+1%
- Rated Output Power: 1800W(Max)
- Output Current: 0~150A
- Output Ripple And Noise: <=120 mVp-p
- Drive And Shut Down Overshoot Range: <=-+5%
- Rise Time: <=100ms(230V rated load test)
- Boot Time: <=3S(230V rated voltage test)
- Hold Up Time: >=10mS(230V rated voltage test)
3. Protection Characteristics:
- Input Under-voltage Protection Point: <=180V
- Input Under-voltage Recovery Point: <=185V
  (Can automatic recovery, the backlash is not less than 5V)
- Input Over-current Protection: Yes
  (The over-current point is between 140~160A)
- Output Short-circuit Protection: Yes
  (Recovery after removal of short circuit)
- Input Over Temperature Protection: Yes
  (When the temperature switch is higher than 100 degrees, protect, turn off the 12V output, and the temperature can be restored automatically below 65 degrees centigrade.)
4. Environment Conditions:
- Operating Temperature: -40~+50℃ Full Load (Typical value is 25 ℃)
- Storage Temperature: -40~+85℃ (Typical value is 25 ℃)
- Operating Humidity: 5~95% Frost-free
- Storage Humidity: 0~95% Frost-free
- MTBF: 50000 H (Typical value is 25 ℃)
- Altitude: <=5000m (Normal Work)
- Heat Dissipation Mode: Air Blast Cooling
