5.8G FPV 8CH 2000MW TS58200 Wireless Audio Video AV Transmitter + RC5808 Receiver Kit for FPV Multicopter

Availability: In stock, usually dispatched in 1 business day

  • Price:$54.33
  • Price in reward points: 543 Reward Points: 5
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $53.24 $52.16 $50.53 $48.35 Contact US
Quantity:

5.8G FPV 8CH 2000MW TS58200 Wireless Audio Video AV Transmitter + RC5808 Receiver Kit for FPV Multicopter

Description:
- 2000mW 5.8G video transceiver suite, 8 channels. Because of the high frequency, the antenna gain and efficiency are high, the transmission distance is far, the channel has no other equipment. Comes with a heat sink and MIC, no need to worry about the heat dissipation problem, can cooperate with 2.4G remote control.
- 2000mW transmitting module adopts wide dynamic range:7-15V power supply (support 2-4S lithium battery. But for camera's sake the 3S vattery or 12V regulation module supply power is necessary. Come with MIC speaker. If you want to adjust the volume, please adjust the potentiometer.

Transmitter main features:
- 5.8GHz video / audio synchronous transmission (compatible with PAL and NTSC)
- Compact structure, small volume, high transmission power (2000mW)
- Integrated micro air cooling radiator, little heat, the work efficiency is high.
- Large-scale integrated circuits, high reliability
- Working voltage DC 7.4V-13V
- 8 working channels, DIP switch option settings
- Built in frequency phase locked loop, low harmonic radiation, high reliability and stability
- Digital phase locked loop circuit, no temperature drift phenomenon
- Working current: 1500mA
- Size: X 31mm x 26mm 69mm
- Weight: 68.5g (including antenna, but not containing wire)

Receiver main features:
- 5.8GHz video / audio sync (compatible with PAL and NTSC)
- Working voltage of DC 9-12V (which can be powered by 3S lithium battery)
- Working current: 1500mA
- 8 working channels, DIP switch option settings
- High reliability and stability
- Digital phase locked loop circuit, no temperature drift phenomenon
- Two independent video / audio output port
- Size: X 70mm x 18mm 100mm
- Weight: 60g (including antenna, but not containing wire)

Working frequency:
CH1:5705 CH2:5685
CH3:5665 CH4:5645
CH5:5885 CH6:5905
CH7:5925 CH8:5945

Note:
- The transmitting antenna must not being off or the power will be ruined
- The receiver: positive inside and negative outside.

Package included:
- 1x RC5808 Receiver
- 1xTS58200 Transmitter
- 2 X 5.8G antennas
- 1 X Power cable for transmitter
- 1 X Power cable for receiver
- 1x Connector and cable set
- 1x Instruction book
