6Axis Agriculture Drone Frame Kit Unassembled 1650mm Load 16KG With Power System For DJI M10

Availability: In stock, usually dispatched in 1 business day

  • Price:$4,417.04
  • Price in reward points: 44170 Reward Points: 442
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $4,328.70 $4,240.36 $4,107.85 $3,931.17 Contact US
Quantity:

6Axis Agriculture Drone Frame Kit Unassembled 1650mm Load 16KG With Power System For DJI M10

Features:

- Strong structure & excellent stability prolong its lifespan.
- Lighter than that of carbon plate lock (6 motor bases) used by the first generation.
- Distribution board was lock by a box on it. It is built with beautiful exterior design, shielding the interference signal.
- Drone arms are built with a horizontally folded structure. Its carbon tubes adopt a special-shaped structure (The end next to the center plate is square and the other end close to motor base is round).
- Made of integrated aluminum alloy, the center plate lasts for long.
- Arm Installation: Directly lock with the matching tube clamp. It is safe and fast. It improves the installation efficiency.

Specifications:
- Axis Numbers: 6-Axis
- Recommended Load Capacity: 16KG
- Wheelbase: 1650mm
- Drone Frame Height: 600mm
- Folded Size: 900mm
- Tube Diameter: 40mm
- Center Plate: Integrated Aluminum Alloy (Including distribution board)

Package Included:
- 1 x 6-Axis Drone Frame (Including landing skid, hood, center plate)
- 1 x Flight Control System: For Jiyi K++ (Including dual GPS)
- 1 x Remote Controller: For Skydroid T12 (With image transmitter and data transmitter)
- 1 x Power System: For DJI M10 Kit (Including motors, ESC, propellers)
- 1 x Spraying System (Including water tank, spray head, 12S brushless pump, flow meter)
- 1 x Terrain Module
- 1 x Obstacle Avoidance Module
- 1 x Flight Case

Note:
- Assembling is needed.
- Flight control, battery, remote control, spray system (medicine box, water pump, spray head, etc.) are not included in the package.
- Battery is not included, we recommend 12-14S 22000Mah 25C battery, you could buy locally or buy from us for 560USD-600USD according to different countries. (Please contact us for Price and shipping issues as for some countries, no shipping method accepts Battery).
