• CJMCU-622 MCP6022 MIC Silicon Microphone Sensor Operational Amplifier

CJMCU-622 MCP6022 MIC Silicon Microphone Sensor Operational Amplifier

Tags: MCP6022, Microphone Sensor Amplifier

Availability: In stock, usually dispatched in 1 business day

  • Price:$8.74
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $8.57 $8.39 $8.13 $7.78 Contact US
Quantity:

CJMCU-622 MCP6022 MIC Silicon Microphone Sensor Operational Amplifier



Product Details:
- "Slim UltraMini" Surface Mount Silicon Microphone with Maximum RF Protection and Ultra Narrow Design
- 1.2APPLICATION  Consumer electronics
- Rail-to-rail Input/output
- Wide bandwidth:10 MHz (typical value)
- Low noise:10MHz hour 8.7 nV/√ Hz (typical value)
- Low offsets voltage
- Industrial temperature grade: +-500uV(the max value)
- Expand temperature grade:+-250uV(the max value)
- Power voltage midpoint VREF:used for MCP6021 & MCP6023
- Low power current:1 mA (typical value)
- Total harmonic distortion:00.00053% (typical value,G = 1 V/V)
- Unit gain stable
- Power voltage range:2.5V 至 5.5V
- Temperature range:Industrial grade: -40℃~+85℃;Expand grade: -40℃~+125℃
- Output method:analog
- Comprehensive,MaxRF protection,sentivity:-42 dbv/pa
- Voltage:3.3V

Application:Automobile;Multipole active filter;audio processing;DAC buffer;device testing;medical instrument.

Package List:
- 1 x Microphone Sensor Operational Amplifier
