Raspberry Pi Pico YD-RP2040 Development Board 16MB 128Mbit Dual Core Raspberry Pi Black/Purple

The Raspberry Pi Pico is a low-cost, high-performance microcontroller development board featuring flexible digital interfaces and versatile development options. It is powered by the RP2040 microcontroller developed by Raspberry Pi, featuring a dual-core Cortex-M0+ processor for ARM running at up to 133MHz, 264KB of SRAM, and 2MB of onboard flash memory. The board provides up to 26 multifunctional GPIO pins, offering flexible connectivity for a wide range of embedded applications.

For software development, the Raspberry Pi Pico supports the official Raspberry Pi C/C++ SDK and MicroPython, allowing developers to choose the programming environment that best suits their needs. With comprehensive development resources, documentation, and tutorials, it enables rapid prototyping, simplifies the learning process, and supports integration into a wide variety of embedded systems and electronic products.

* Features the RP2040 microcontroller independently designed by Raspberry Pi.

* Powered by a dual-core Cortex-M0+ processor for ARM with a flexible clock configuration and a maximum operating frequency of 133MHz.

* Equipped with 264KB of SRAM and 16MB of onboard Flash memory.

* Supports USB 1.1 host and device functionality.

* Supports low-power sleep and dormant modes for reduced power consumption.

* Enables USB mass storage recognition for convenient drag-and-drop program downloading.

* Provides up to 30 multifunctional GPIO pins for flexible peripheral connectivity.

* Integrates 2 SPI interfaces, 2 I2C interfaces, 2 UART interfaces, 4 12-bit ADC channels, and 16 controllable PWM channels.

* Features a precision on-chip clock and timer system for accurate timing and scheduling.

* Includes an integrated temperature sensor for on-chip temperature monitoring.

* Supports accelerated floating-point operations through an optimized on-chip library.

* Provides 8 programmable I/O (PIO) state machines for implementing custom interfaces and peripheral protocols.

* Comes pre-flashed with MicroPython firmware, enabling immediate MicroPython development.

* Board Size: 52mm x 19mm.

* 1 x Development Board

* 2 x Long Pin Headers

* 1 x Short Pin Header

* Package weight: 0.15kg
