HELTEC Automation WiFi LoRa 32 (V4) ESP32 SX1262 Meshtastic 0.96-Inch OLED Solar Powered 863-928MHz Optional GPS
$37.48 - $47.48
Včetně daní.
Poštovné se vypočítá na pokladně.
Běžná cena
$37.48
Běžná cena
Výprodejová cena
$37.48
Jednotková cena
za
Dostupnost vyzvednutí nebylo možné načíst
Availability:
2000 skladem
SKU:
102549
Tags:
Collections:
Běžná cena
$37.48
Běžná cena
Výprodejová cena
$37.48
Optional Type:
* Without GPS
* With GPS
Summary:
Heltec WiFi LoRa 32 V4 is a fully upgraded version of the classic LoRa development board. Since its initial launch in 2017, this product series has been highly favored by developers and makers. Building upon the powerful features of its predecessors, the V4 version introduces comprehensive optimizations in Transmit Power, power management, expandability and other hardware design. It is suitable for various IoT applications such as smart cities, agricultural monitoring, smart homes, industrial control, security systems, and wireless meter reading, providing developers with a more efficient and flexible development experience.
Features:
* Base on ESP32-S3R2 & SX-1262, supports Wi-Fi b/g/n, BLE, and LoRa communication.
* 2MB PSRAM and 16MB external Flash, more suitable for UI and complex system .
* High-power version with LoRa transmission power increased to 27±1dBm.
* Form factor and pin compatibility with WiFi LoRa 32 V3.
* PC casing protects the screen and integrates FPC 2.4G antenna.
* Added SH1.25-2P solar panel interface.
* Optimized lithium battery management.
* Added SH1.25-8Pin GNSS interface.
* USB Type-C interface with integrated voltage regulation, ESD protection, short-circuit protection, and RF isolation design.
* Low power consumption is less than 20μA.
Packing List (Depending on Selected Configuration):
Without GPS:
* WiFi LoRa 32 (V4) x1
* LoRa Antenna x1
* 1.25×2 Connector (for battery & solar) x2
* 2.54*18 Header Pin x2
* 2.54*2 Header Pin x2
With GPS:
* WiFi LoRa 32 (V4) x1
* LoRa Antenna x1
* 1.25×2 Connector (for battery & solar) x2
* 2.54*18 Header Pin x2
* 2.54*2 Header Pin x2
* GPS Module x1
Packaging Details (Depending on Selected Configuration):
Without GPS:
* Package weight: 0.2kg
With GPS:
* Package weight: 0.25kg
Note:
* Battery is not included.
* All units of the 863-928MHz model currently on sale are high-power versions (28±1dBm).
