Original IC-7300MK2 HF/50MHz Shortwave Radio Transceiver Built-in CW Decoder with 4.3-Inch IPS Touch LCD for ICOM

Reminder:
- 70MHz available on the Europe Version.

New Characteristics:
- The HDMI-compatible interface used to connect external displays can transmit audio and video signals from radio stations to external displays.
- The RX-ANT input/output interface can be used to connect filters, preamplifiers, or receiving antennas.
- Built in CW decoder, used to decode CW signals into text information and display it on the screen.
- Ethernet interface (LAN) facilitates remote control of radio stations using optional RS-BA1 (Version 2) software.
- USB Type-C interface, with two virtual COM ports and audio input/output functions.
- The Audio Peak Filter (APF) allows you to set excellent selectivity in CW mode.

Enhanced Performance:
- Enhanced RMDR and phase noise characteristics: The RMDR performance of IC-7300MK2 has been improved, with a typical value increased to about 12dB. Compared with the previous generation, its transmission phase noise characteristics have also been improved by about 12dB. The superior phase noise characteristics help reduce noise components in the received and transmitted signals.
- Through component selection and power optimization, IC-7300MK2 generates less heat during operation and can maintain stable operation even after prolonged use. Compared with the previous generation, its standby current consumption has decreased from 0.9A to 0.7A (typical value). The fan control has also been optimized to reduce noise during operation.

Core Functions:
- IC-7300MK2 adopts RF direct sampling technology, which can directly convert RF signals into digital data and process it in FPGA. This technology greatly simplifies the circuit architecture while providing excellent performance.
- Advanced "IP+" technology: The "IP+" function significantly improves intermodulation distortion (IMD) performance. When a weak signal is adjacent to strong interference, it intelligently optimizes the AD converter to ensure clear reception.
- It has high-performance real-time spectrum display function, high-resolution waterfall display wall function, and audio spectrum function, providing intuitive operability and excellent visibility on a large 4.3-inch color IPS touch screen LCD.
- IC-7300MK2 adopts 15 independent RF bandpass filters with high-Q coils, which have excellent out of band interference suppression capability.
- The built-in automatic antenna tuner of the radio can automatically match antennas with impedance ranging from 16.7 to 150 ohm (standing wave less than 3:1), and has a tuning memory function for quick tuning.
- The combination of multifunctional knobs and touch screens provides a fast and efficient operating mode.
- One click switch to FT8 mode: Simply select [FT8] from the preset menu to automatically configure all necessary settings for FT8 mode, or select [Normal] to return to normal operation.
- Automatic competition sequence numbering: This feature is very practical in CW and RTTY competitions, as the sequence number automatically starts counting from 001 every time pre programmed stored content is sent. The serial number can be set in multiple locations to ensure reliable replication of the competition number.
- High performance speakers are placed in dedicated acoustic spaces, providing high-definition sound quality regardless of volume.
- Various data can be stored on SD memory cards, such as communication recordings, voice storage, RTTY decoding logs and screenshots, as well as radio station settings. Supports SD cards with a maximum capacity of 2G (not included), SDHC cards with a maximum capacity of 32G (not included), or SDXC cards with a maximum capacity of 256G (not included).

Specification:
- Model: IC-7300MK2
- Frequency range:
  Receiving: 0.03 - 74.8MHz
  Transmitting: 1.8 - 50MHz (USA version, for amateur band only); 1.8 - 70MHz (EUR version, for amateur version only)
- Circuit type: RF direct sampling
- Working mode: SSB/CW/FM/RTTY/AM
- Channel number: 101
- Transmitting power:
  SSB/CW/FM/RTTY: 0.6-100W (HF/50MHz)/0.3-50W (70MHz)
  AM: 0.125-25W (HF/50MHz)/0.075-12.5W (70MHz)
- Power supply voltage: DC13.8V±15%
- Current consumption: 21A (transmitting, maximum power); 0.7A (receiving, standby); 1.25A (receiving, maximum volume)
- Working temperature: -10℃ to 60℃
- Antenna interface: M female
- Antenna impedance: 50 ohm
- Net weight: 4.1kg
- Product size: 240 x 94 x 237.6mm

Package Included:
- 1 x Transceiver
- 1 x Handheld Microphone
- 1 x ACC Plug (13Pin)
- 1 x CW Plug (6.35mm)
- 1 x Speaker Plug (3.5mm)
- 1 x DC Power Cord
- 1 x Spare Fuse (58V 5A)
- 1 x Spare Fuse (32V/30A) for EUR Version/Spare Fuse (32V 25A) for USA Version
