3 DOF Mechanical Arm Robotic Arm Manipulator Teaching Kit with Digital Servo Air Pump Control Board

3 DOF Mechanical Arm Robotic Arm Manipulator Teaching Kit with Digital Servo Air Pump Control Board

Servo Parameters:
Torque (4.8V): 150kg/mg
Torque (6.6V): 200kg/mg
Speed: 0.07 seconds (4.8V)|006 seconds
Working voltage: 4.8V 6.6V DC voltage
Weight: 55g
Bearing type: ball bearing×2
Motor type: strong magnetic high-speed motor
Gear type: copper aluminum
Working temperature: -20℃-60℃
Working frequency: 500μs/2500Hz

Control Board:
Arduino control board

Servo Type Air Pump Valve
Instructions for Use:
The so-called servo air pump valve means that the control principle is the same as that of the servo. The code and program are common, greatly facilitating the unified setting and management of the program. The air pump and valve are directly connected to the control board interface like the servo without additional controller and power supply. The control method is simple and easy to use, and the air pump and valve are controlled separately. When the pulse width is more than 2000μsec, the air pump or valve starts to work; when the pulse width is less than 1000μsec, it stops working. (It is recommended to turn on for 2500μs and turn off for 500μsec, which is equivalent to 180° of the servo to turn on and 0° to turn off)

Package List:
1 x Mechanical Arm with Air Pump Control Board

Note: Not include other items displayed in the picture.
