DC-DC Converter LTC3780 High-Power Automatic Step-UP Step-Down Power Board Module
Specification:
- Input voltage:5-32V
- Output voltage:2-24V
- Output current:0.01-14A
- To adopt advanced technology for synchronous rectifier, conversion efficiency up to 98%
- Working frequency :200KHz
- Output over current, short circuit protection, output even if short circuit will not be afraid, will automatic protection circuit
- Input with 15A fuse, added level of security and protection measures
- Chip with overheating protection, over temperature automatically stop working
- Input under-voltage protection, the input voltage is lower than 4.5 V when stop working
- No input reverse connect protection, input/output will burn
- Soft start function, make sure no overshoot voltage in the process of electricity
- It can directly control the output voltage of the switch, directly grounding can shut down the output voltage, module into sleep mode. Don't pick up (suspended) or open output
- Full load temperature :rise to 50 ?, shipment has been shipped heat sink, strengthen heat dissipation
- Working temperature:-45~85
- Volume:85mm*48mm*25mm
- Connection mode: terminal type
Packing List:
- 1 x Module
