SLAMTEC RPLIDAR S3 (S3M1) 40m TOF Lidar for Indoor Outdoor Uses and Large-screen Interactive Projects

1. TOF Lidar:

* RPLIDAR C1

* RPLIDAR S2 (S2M1)

* RPLIDAR S3 (S3M1)

* It realizes 360° scanning ranging.

* C1 is for indoor use, while S2 and S3 support both indoor and outdoor environments.

* S2 and S3 are widely applied in large-screen interactive projects.

2. Triangulation Lidar:

* RPLIDAR A1 (full model: A1M8)

* RPLIDAR A2 (full model: A2M12)

* RPLIDAR A3

* Supports 360° scanning ranging, designed for indoor scenarios, and outputs data via UART serial port

RPLIDAR S3 Lidar Sensor

* Smaller size, better performance

* Compatible with Slamtec ecosystem for hassle-free upgrade

* Measuring Radius: 40m

* Sampling Frequency: 32k

* Angular Resolution: 0.1125°

* Application Scenario: Indoor and outdoor use

* Protection Grade: IP65

Slamtec Self-developed SL-TOF Ranging Technology

* It adopts SLAMTEC Direct Time of Flight (SL-TOF) laser time-of-flight ranging technology independently developed by Slamtec, featuring outstanding resistance to ambient light interference and stable measurement performance to deliver superior ranging results.

Stable 40m Measuring Radius

* Even under a 70% reflectivity condition, the measuring radius can steadily reach 40 meters, satisfying mid-to-long distance ranging requirements.

Guaranteed Safety: Stable 15m Measuring Radius for Low-reflectivity Objects

* RPLIDAR S3 maintains excellent ranging performance when facing challenging low-reflectivity objects such as dark-colored surfaces, achieving a measuring distance of 15 meters at 10% reflectivity.

* Measuring distance for black objects reaches 15m (10% reflectivity)

* High detection rate for high-reflective objects like mirrors and glass

High-speed Sampling Capacity of 32,000 Times Per Second

* RPLIDAR S3 delivers outstanding performance in real-time perception, precise positioning and target detection. Its high sampling frequency generates abundant point cloud data to enable faster and more accurate mapping.

80KLux Ambient Light Interference Resistance

* With optimized hardware technology, RPLIDAR S3 can efficiently resist ambient light interference under strong indoor light, direct outdoor sunlight and other scenarios, delivering precise laser ranging data.

Compact & Thin with Superior Performance

* RPLIDAR S3 features a compact and streamlined body with an overall height of only 41.3mm, making it the smallest LiDAR product of Slamtec. It breaks space limitations, fits a wide range of application scenarios, and delivers high cost performance.

Compatible with Slamtec Ecosystem

* RPLIDAR S3 maintains high compatibility with Slamtec software and hardware interfaces as well as its ecosystem, enabling seamless replacement with existing Slamtec products without extra adaptation work.

Supports Multiple Development Platforms

* SLAMTEC provides users with SDK development kits compatible with x86 Windows, x86 Linux, arm Linux and other platforms to facilitate development and integration across various operating systems and architectures.

* It supports ARM, ROS and C++.

Class 1 Laser Safety Standard

* It adopts modulated pulse low-power infrared laser as light source, conforming to Class 1 laser safety standard and reaching eye-safe level.

Application Scenarios

* Service robot navigation and obstacle avoidance

* Obstacle detection and avoidance for AGV robots

* Parking space monitoring in parking lots

* Environmental perception and autonomous movement of low-speed unmanned vehicles

* Multi-touch and large-screen interactive projection

* UAV mapping and obstacle avoidance

* Mapping and obstacle avoidance for ROS/educational robotic vehicles

* Environment scanning and 3D reconstruction

* 1 x RPLIDAR S3 Radar Sensor

* 1 x Serial Port Adapter
* 1 x USB Cable
* 1 x Power Cable

* Package weight: 0.42kg
