34x34x12mm/1.3x1.3x0.5" RF Shield Box CNC Machined Aluminum Shell + Four SMA Female Connectors
Prix habituel
$19.84
Prix habituel
Prix soldé
$19.84
Prix unitaire
par
Taxes incluses.
Frais d'expédition calculés à l'étape de paiement.
Impossible de charger la disponibilité du service de retrait
Prix habituel
$19.84
Prix habituel
Prix soldé
$19.84
34x34x12mm/1.3x1.3x0.5" RF Shield Box CNC Machined Aluminum Shell + Four SMA Female Connectors
Description:
The microwave shield box is made of die-casting aluminum and CNC machined. It comes with SMA connectors. It can be used for low-noise amplifiers, power amplifiers and professional RF design.
Specifications:
1. Dimensions (without the size of connectors): 34 x 34 x 12mm/1.3 x 1.3 x 0.5" (2mm/0.08" box cover)
2. Cavity size (mainly PCB version): 26 x 26 x 6mm/1 x 1 x 0.2" (chamfer R=1.5mm/0.06" inside the cavity)
3. Recommended size of circuit board: over 0.5mm/0.02" smaller than the cavity size
4. Shell weight: 46g/0.1lb
5. Connector model: SMA-KFD46 (female)
Package Included:
- 1 x Shell body
- 1 x Box cover
- 4 x SMA female connectors
Packaging Details:
- G.W.: 0.2kg
