Product Details:
- Integrated metal shell with polished treatment and thick gold-plated ports, strengthen anti-interference, anti-corrosion and anti-oxidation function, support input different HD videos, making sure transfer at high speed.
- Super over-current protection, greatly improve safety and stability while using.
- Multiple holes design on side, bring excellent heat dissipation, effectively extend its lifespan.
- Comes with remote controller, convenient to use it.
- Equipped with 1 HDMI output and 4 HDMI input interfaces.
- Support cuttings images on 1 monitor from 4 HDMI hosts.
- Support switch image on 1 monitor from 4 HDMI hosts seamlessly.
- Support 1080P@60Hz output
- Support split coaxial audios
- Support LPCM/Dolby 5.1/DTS 5.1 format
- Support IR control, smart EDID management
- Support RS232 serial online control or upgrade
- Support multiple HDMI format output
- Built-in scale up, scale down function
- E50IR receiver with ARC Audio return.
- Effective Distance for connection Cable: 15m(1080P/60Hz, 8bit)
Specifications:
- Item Name: HDMI Splitter
- Model No: RO-8401
- Color: Black
- Power: 6W Max.
- Protocol: HDCP 1.4, HDMI 1.4B dvi 1.0
- Shell: Metal
- Video Broadband Speed: 6.75Gbps
- Working Temperature: 0 to 40℃/32 to 104℉
- Color Space: RGB, YCbCr 4:4:4, YCbCr 4:2:2
- Storage Temperature: -20 to 60℃/-4 to 140℉
- Color Depth: 10-bit, 12-bit
- Resolution: 1080P@60Hz, 720P@60Hz, 480P@60Hz
- Input Interface: 4 x HDMI Type A(19-pin female port)
- Output Interface: 1 x HDMI Type A(19-pin female port), 1 x RS-232 (3.81mm) Phoenix connector
- Electrostatic Protection: Human body model- 8KV(air-gap discharge) & 4KV (contact discharge)
- Power Supply: Input: AC 100-240V 50/60Hz; Output: DC 5V/2A (US/EU standard, CE/FCC/UL certified)
- HDMI Audio Format: LPCM 2/5.1/7.1CH, Dolby digital, DTS 5.1, Dolby Digital+, Dolby TrueHD, DTS-HD Master Audio, Dolby Atmos, DTS:X
- Size: 185 x 79.8 x 19 (mm)
- Gross Weight: 0.3kg
Package Included:
- 1 x HDMI Splitter
- 1 x Adaptor
- 1 x Remote Control
- 1x RS-232 Connector
- 1 x Manual
