HIFI Class 2.0 Dual Channel Stereo Digital Amplifier TPA3116 50W+50W Power Audio Amp-Blue

HIFI Class 2.0 Dual Channel Stereo Digital Amplifier TPA3116 50W+50W Power Audio Amp


Instruction:
- Do not use cheap audio signal cables, these cables are without shieldiing, they will lead in high frequency noises. The bigger the rotation, the larger the noises
- The correct using sequence is first  connect laptop power with amp power supply port, then charge the laptop.

Specification:
- Adopting top red ring output inductance, no output consumption, more pure sound voice
- Full allumnium alloy body, gold plated RCA and crystal loudspeaker line column, more gorgeous
- Adopts Germany MKP10 as output, more rich overtone
- Adopts high speed capacitor array. lower internal resistor, dynamic more violent
- Gold plated RCA port output, Taiwan imported sealed potentiometer, thicken allumnium alloy radiating

Power Voltage:
12V - 8ohm loudspeaker/12W(left channel) + 12W(right channel)  4ohm loudspeaker/20 (left channel) + 20W(left channel )
15V - 8 ohm/18 + 18W , 4Ohm/ larger than 30 + 30W
19V - 8 ohm/32 + 32W , 4Ohm/ larger than 45 + 45W
24V - 8 ohm/38 + 38W , 4Ohm/ larger than55 + 55W

Product Description:
- Douk Audio Stereo Mini Power Amplifier 50W×2
- This is the latest version, perfect circuit layout and components. No extra fancy, Mini, Compact, Simple and Practical, the best HiFi and Cost-effective power amplifier.

Parameters:
- Chip: TPA3116D2
- Channel: 2.0
- Max. output power: 50W+50W
- Chassis size: (W) 90 * (H) 35 * (L) 108 mm
- Power range: DC 12-25V (Recommend to use hi-end power adapter)
- 1 set of Stereo L/R RCA input, 1 set of Banana Speaker Jacks

Note: No power adapter

Package included:
- 1 x Digital power Amplifier
