LHY AUDIO Hi-End Digital Audio Player Bluetooth 5.0 AES Coaxial Optical I2S Output Standard Version

LHY AUDIO Hi-End Digital Audio Player Bluetooth 5.0 AES Coaxial Optical I2S Output Standard Version

Version Introduction:
Standard Version: Chinese interface; active crystal oscillator; digital transformer for MuRata

Description:
Powered by UV-class batteries, it converts AC power into DC power, providing the purest power source and greatly reducing interference. Battery power supply provides clean enough power for each device, solves the problem that traditional AC power supply sound is greatly affected by the environment, and makes the sound more stable and quieter. Since the signal of this product does not need to be amplified, the power consumption is only 300mA, so there will be no transient and insufficient dynamics, and the storage capacity can be used continuously for 40 hours.

The output interface has AES / RCA coaxial / optical / HDMI (i2s). The input method is Bluetooth / USB. AES/coaxial is output independently through digital isolation transformer, and i2s is output independently through LVDs chip, which reduces interference and makes the output signal more pure. Among them, there is an i2s dial switch on the device, and users can adjust the i2s line sequence according to the device, or provide information for us to adjust in advance.

It adopts Bluetooth 5.0 protocol receiving technology, supports Bluetooth 5.0 protocol, and supports for aptX/aptX-HD encoded audio transmission.

The Bluetooth signal output is up-converted to 192khz.

Audiophile audio components. CCHD-957 signal is more stable. Large-capacity battery power supply is very pure uV level. The CSR8675 Bluetooth module signal is up-converted to 192KHz. WM8805 low jitter 50PS RMS, i2s to spdif signal. SRC4192 has high performance and low jitter, sampling rate conversion dynamic range 144db, THD+N 140db. ADP150 ultra-low noise voltage regulator.

Specifications:
- Model: 2489
- Input interface: USB-B, Bluetooth 5.0
- Output interface: coaxial RCA, AES, optical fiber, HDMI-IIS
- Bluetooth module: CSR8675 Bluetooth 5.0
- Bluetooth support: For SBC/AAC/APTX/APTX-LL/APTX-HD/LDAC
- I2S (HDMI) support: 384K/32BIT, DSD64, DSD128, DSD256. The interface is compatible with multiple HDMI definitions (such as for PS audio/Gustard, HOLO Spring)
- Fiber/Coaxial/AES/Bluetooth support: 192Khz/24bit
- USB digital interface: Chinese interface
- Power supply mode: internal battery power supply, can be charged via type-c charging cable for Android
- Size: 48 x 158mm/1.9 x 6.2"
- Net weight: 700g/1.5 lb

Package Included:
- 1 x Set of Bluetooth Player
