LS237 3500μm Rechargeable Car Coating Thickness Gauge Meter (Integrated Type with Rotating Screen)

LS237 3500μm Rechargeable Car Coating Thickness Gauge Meter (Integrated Type with Rotating Screen)

Description:
The LS237 Car Paint Thickness Gauge is professionally designed for automotive paint thickness detection. The device not only measures the paint thickness on iron and aluminum surfaces but also identifies non-metallic car bodies. It can intelligently detect iron powder putty layers and iron-galvanized layers, giving a clear view of the car's condition. The LS237 features three-color backlighting and three-color indicator lights, with different colors on the screen and buttons corresponding to various paint thicknesses, making it easy to understand the paint thickness. The LS237 screen is rotatable for convenient reading. It is powered by a rechargeable lithium battery with ultra-low power consumption. Additionally, the device includes Bluetooth functionality, along with a mini program and app for generating and sharing vehicle inspection reports.

Features:
Smart Identification of Iron Powder Putty
* The instrument can automatically identify iron powder putty. During measurement, it emits two beeping sounds, and both the screen backlight and button indicator light turn red.

Multi-Purpose, Smart Identification of Car Body Materials
* The device can quickly detect iron, aluminum, iron-galvanized, and non-metallic car bodies. It is versatile, making car body material identification easy.

Three-Color Display, Easy to Read Paint Thickness
* The three-color display can be turned on or off in the settings. When enabled, the screen backlight and button indicator light show three colors based on the paint thickness:
1. White backlight and green indicator light: when the paint thickness is less than 170μm.
2. Yellow backlight with yellow indicator light flashing twice: when the paint thickness is between 170μm and 350μm.
3. Red backlight with red indicator light flashing twice: when the paint thickness is greater than 350μm or iron powder putty is detected.

WeChat Mini Program and App for Generating Vehicle Inspection Reports
* With Bluetooth data transmission, the device can connect to the WeChat Mini Program or mobile app for operation. It can generate test reports from the measurement data and allows you to save or share the reports.

Phone Number Binding to Prevent Loss
* By binding your phone number through the mini program, the device displays your phone number when powered on, preventing loss.

Rechargeable Lithium Battery and Ultra-Low Power Consumption
* Powered by a rechargeable lithium battery and charged through a type-c interface. The device features ultra-low power consumption, allowing for more than 50 hours of continuous use on a single charge.

Fast Measurement Speed. No Waiting
* The instrument has an ultra-fast response speed, completing a measurement in just 0.5 seconds.

Ruby Probe: Hard and Wear-Resistant
* The device uses a hard, wear-resistant ruby probe, reducing measurement errors caused by wear and extending the instrument's lifespan.

Digital Probe for More Precise Measurements
* The device uses advanced digital probe technology, with digital signal processing directly handled in the probe. The probe is less prone to interference and provides excellent testing accuracy, ensuring good repeatability throughout the entire measurement process and stable data.

Rotatable Display for Easy Reading
* When the rotatable display is enabled in the settings, a short press of the power button allows the screen to rotate, making it more convenient to read the measurements.

Additional Features
* No need for calibration, just zeroing. The single-button design makes operation simple.
* Units can be switched between μm and mil.

Packing List:
* 1 x LS237 Paint Thickness Gauge

Packaging Details:
* Weight: 0.55kg
