MX321 Generator AVR Automatic Voltage Regulator Multi-function Voltage Regulator Excitation Board

Availability: In stock, usually dispatched in 1 business day

  • Price:$70.74
  • Price in reward points: 707 Reward Points: 7
  • Quantity 3+ units 10+ units 30+ units 50+ units More
    Price /Unit $69.33 $67.91 $65.79 $62.96 Contact US
Quantity:

MX321 Generator AVR Automatic Voltage Regulator Multi-function Voltage Regulator Excitation Board

Features:

- MX321 automatic voltage regulator
- Durable to use
- Stable performance
- Fast response
- Operate freely in high temperature environment

Specifications:
- Model: MX321
- Detection input: 190-264VAC two-phase or three-phase
- Power supply input: 170-220VAC three-phase three-wire
- Magnetic field output: voltage maximum 120VDC current continuous 3.7A, non-continuous 10 seconds 6A
- Voltage regulation accuracy: <±1% RMS (engine speed change within 4%)

Package Included:
- 1 x AVR
