NerdAxe Ultra BM1366 500GH/s 15W BTC Miner Bitcoin Lottery Miner (with Black Shell and Silent Fan)

NerdAxe Ultra BM1366 500GH/s 15W BTC Miner Bitcoin Lottery Miner (with Black Shell and Silent Fan)

Description:
NerdAxe is a fully open-source Bitcoin ASIC miner equipped with the BM1366 ASIC chip from Antminer's S19XP.

This design ensures efficient and powerful mining capabilities, achieving 500 GH/s at an energy efficiency of 20 J/TH. It operates using a 5V DC power supply connected via a 2.1/5.5mm barrel jack connector.

At the core of NerdAxe is the combination of ESP-miner and AxeOS, an open-source firmware that empowers you with full control over your mining operations. The intuitive web interface simplifies setting adjustments and performance monitoring, making mining more accessible and streamlined.

NerdAxe is an open-source miner based on Bitaxe project, designed to boost the hashing power of your NerdMiner.

Features:
* BM1366 ASIC Chip: The 500 Gh/s ASIC chip for Bitmain works at low temperature with fan
* AXEOS WebConfig: View global miner statistics, current hashrate, configuration settings, and logs
* Main Screen: The screen provides all NerdAxe stats, including mining values, chip temperature, and efficiency, among other details.
* Stats Screen: The screen shows your configured settings, including the pool, IP address, and port for configuring axeOS. The screen displays mining data in real-time, including hashrate, uptime, efficiency, shares, etc.
* High Performance: Powered by the S19XP BM1366 ASIC chip
* Easy to Plug and Play: Easy to setup, fully assembled, configure and play
* ASIC Tuning: Fine-tune your ASIC performance through the configuration portal
* Config Portal: Web config portal to set up your mining data

Specifications:
* Vcc: 5V
* Imax: 3A
* Power: 12W~15W
* USB type: USB-C
* Wifi: only 2.4GHz
* MCU: ESP32-S3R8 Dual-core LX7 microprocessor
* ASIC Chip: BM1366

Packing List:
* 1 x BTC Miner
* 1 x Power Adapter
* 1 x Power Cable
* 1 x User Manual

Packaging Details:
* Weight: 0.55kg
